Arham Stainless is a leading supplier of wide range of Stainless Steel Flat Bar. SS Flat Bars are used by Grating manufactures, automobile, cable trays, bright bar industries and auto-ancillaries, Truck trailers, Tippers, Railways, elevators and escalators, bus body, Scaffolding manufacturers, Earthing material, Base plates, Ship building, washers, flanges, clamps and many more engineering industries.
♦ Stainless Steel Flat Bar Sizes ♦
Size Range
| Size (mm) | Size (inch) | Thickness (mm) | Thickness (in Inches) |
| 22 mm | 7/8” | 17 mm & 18 mm | 2/3” - 5/7" |
| 25mm | 1" | 5 mm to 20 mm | 3/16” - 4/5” |
| 30 mm | 1-3/16" | 5 mm to 20 mm | 3/16” - 4/5” |
| 32mm | 1-1/4" | 6 mm to 20 mm | 1/4” - 4/5” |
| 35mm | 1-3/8" | 5 mm to 20 mm | 3/16” - 3/16” |
| 40mm | 1-4/7" | 5 mm to 25 mm | 3/16” - 1” |
| 45mm | 1-7/9" | 5 mm to 25 mm | 3/16” - 1” |
| 47 mm | 1-6/7" | 17,25 & 32 mm | 2/3”, 1” & 1-1/4” |
| 50mm | 2" | 5 mm to 32 mm | 3/16” - 1-1/4” |
| 55mm | 2-1/16” | 5 mm to 25 mm | 3/16” - 1” |
| 57 mm | 2-1/4” | 32 mm | 1-1/4” |
| 60 mm | 2-3/8” | 5 mm to 35 mm | 3/16” - 1-3/8” |
| 63mm | 2-1/2" | 10 mm to 30 mm | 3/8” - 1-3/16” |
| 65mm | 2-5/9" | 10 to 30 & 35 mm | 3/8” - 1-3/16”, & 1-3/8” |
| 70mm | 2-3/4" | 6 mm to 25 mm & 40 mm | 1/4” - 1”, & 1-4/7” |
| 75mm | 3" | 8 mm to 25 mm | 5/16” - 1” |
| 80mm | 3-1/8" | 8 mm to 20 mm | 5/16” - 4/5” |
| 90mm | 3-1/2" | 8 mm to 20 mm | 5/16”- 4/5” |
| 100mm | 4" | 8, 10, 12 | 5/16”, 3/8”, 1/2” |
